22 AERO XR C3000
2022

SHIMANO

22 AERO XR C3000

Compatibility & maintenance

This page brings together the exploded view, the compatible parts and maintenance solutions for the SHIMANO 22 AERO XR C3000 (2022).

Find the reel bearings, ball bearings, roller bearing, Carbontex brakes, genuine spare parts and accessories for this model.

Diagram available
Original, compatible & custom
Fast delivery
Technical expertise

Roller bearing

4 items available

Carbontex

1 item available

Ball bearings

6 items available
See the diagram
Diagram No.Part numberAction
8553
R18 dès 10,99 €
8554
R12 dès 13,29 €
12969
R19 dès 10,99 €
13269
R05 dès 10,39 €
17698
R05 dès 10,39 €
20644
R07 dès 10,39 €

Spare parts

77 références disponibles
Use the drawing number to locate the part on the exploded view
Diagram No.Manufacturer's referenceDescriptionOrder
8553 107AT Ball Bearing Ball Bearing
R18 dès 10,99 €
8554 107FE Ball Bearing Ball Bearing
R12 dès 13,29 €
12969 107FA Ball Bearing Ball Bearing
R19 dès 10,99 €
13269 104VX Ball Bearing Ball Bearing
R05 dès 10,39 €
17698 10PXZ Handle Knob Bushing Handle Knob Bushing
R05 dès 10,39 €
20644 10RKR Ball Bearing Ball Bearing
R07 dès 10,39 €
0582 108WH O Ring O Ring —
3455 10BXN Spool Washer Spool Washer —
4798 103C6 Screw Screw —
8916 10CH0 Click Spring Click Spring —
10345 10N5A Drag Washer Drag Washer
Carbontex for Shimano Spinning S#1 13,99 €
10752 10TYE Bail Spring Guide A Support Bail Spring Guide A Support —
11077 10MZX Drag Washers Retainer Drag Washers Retainer —
12078 10PH4 Screw Screw —
14829 10PH3 Drag Click Spring Drag Click Spring —
14832 103MU Spool Support A Spool Support A —
14833 10J04 Spool Support B Spool Support B —
15416 1038H Drag Click Drag Click —
16774 10BCE Key Washer Key Washer —
17145 105B4 Anti-Reverse Cam Spring Anti-Reverse Cam Spring —
17192 1067Y Rotor Nut Rotor Nut —
17194 106P2 Bail Trip Lever Bail Trip Lever —
17251 10QPN Roller Clutch Assembly Roller Clutch Assembly —
17332 10R1P Screw Screw —
17372 10LCE Screw Screw —
17415 106ZC Click Pin Click Pin —
17682 1061L Bail Spring Guide A Bail Spring Guide A —
17683 105R6 Bail Spring Bail Spring —
17684 107AB Bail Spring Seat Bail Spring Seat —
17690 104FV Friction Ring Friction Ring —
17700 10LFA Screw Screw —
17701 10TNJ Handle Knob Seal Handle Knob Seal —
17849 10DMK Main Shaft Main Shaft —
17857 10DMG Pinion Gear Pinion Gear —
17879 10LA3 Screw Screw —
17991 10LFL Screw Screw —
18022 10JVH Washer Washer —
18681 10PMH Screw Screw —
18741 10SYU Washer Washer —
18821 101WL Screw Screw —
19010 100MF Washer Washer —
19745 104FH Washer Washer —
19792 10187 Line Roller Collar Line Roller Collar —
19803 10RSK Screw Screw —
19831 1009E O Ring O Ring —
19837 1009K Line Roller Bushing Line Roller Bushing —
19839 10RFZ Line Roller Spacer Line Roller Spacer —
20370 103DA Screw Screw —
21106 103NA Screw Screw —
21178 10EEZ Washer Washer —
21812 10TB2 Anti-Reverse Cam Anti-Reverse Cam —
21814 10TBF Oscillating Guide Oscillating Guide —
21815 10TBH Bushing Bushing —
21817 100QJ Oscillating Gear Oscillating Gear —
21818 100KG Oscillating Slider Oscillating Slider —
21820 10T8W Drive Gear Drive Gear —
22110 100HA Anti-Reverse Lever Anti-Reverse Lever —
22326 10R68 Drag Knob Drag Knob —
22327 10R6B Spool AERO XR C3000 Spool AERO XR C3000 —
22328 102XX Washer Washer —
22329 10S72 Counter Weight Counter Weight —
22331 10R6D Bail Spring Cover Bail Spring Cover —
22332 10R69 Bail Arm Bail Arm —
22333 10G6F Spacer Spacer —
22334 10SU2 Line Roller Line Roller —
22335 10QY7 Bearing Spacer Bearing Spacer —
22336 10SJB Bail Assembly Bail Assembly —
22337 10R6H Line Roller Support Line Roller Support —
22338 10SJC Body Body —
22339 10R6E Rear Protector Rear Protector —
22340 100EH Screw Screw —
22341 10R6G Side Cover Side Cover —
22342 10R78 Handle Assembly Handle Assembly —
22343 10R6F Spare Spool AERO XR C3000 Spare Spool AERO XR C3000 —
22344 10R6A Spool Economizer (Accessory) Spool Economizer (Accessory) —
22418 10RPB Bushing Spring Bushing Spring —
22557 13XFB Rotor Rotor —

Custom Parts

1 item available

Maintenance in our workshop

See our packages

Leave your reel in the hands of our technicians for a full service: cleaning, lubrication, replacement of worn parts and a general check-up.

Discover our maintenance packages
