This page brings together the exploded view, the compatible parts and maintenance solutions for the SHIMANO 10 Baitrunner 4000 D (2010).
Find the reel bearings, ball bearings, roller bearing, Carbontex brakes, genuine spare parts and accessories for this model.
| Diagram No. | Part number | Action |
|---|---|---|
| 13241 |
R18
dès 10,99 €
|
|
| 13374 |
R12
dès 13,29 €
|
|
| 13241 |
R18
dès 10,99 €
|
|
| 13374 |
R12
dès 13,29 €
|
| Diagram No. | Manufacturer's reference | Description | Order |
|---|---|---|---|
| 13241 | RD13241 Ball Bearing | Ball Bearing |
R18
dès 10,99 €
|
| 13374 | RD13374 Ball Bearing | Ball Bearing |
R12
dès 13,29 €
|
| 71 | 10MSQ Rotor Nut | Rotor Nut | — |
| 642 | 10M35 Clutch Plate Screw | Clutch Plate Screw | — |
| 786 | 103J1 Screw | Screw | — |
| 787 | 103L6 Bearing Retainer Screw | Bearing Retainer Screw | — |
| 2264 | 10B8C Drag Washers Retainer | Drag Washers Retainer | — |
| 2516 | 103PA Spool Support | Spool Support | — |
| 2613 | 105N4 Washer | Washer | — |
| 2918 | 105S3 C Lock | C Lock | — |
| 3179 | 10BE4 Washer | Washer | — |
| 3402 | 103ND Screw | Screw | — |
| 3492 | 103DC Screw | Screw | — |
| 3503 | 10BXK Spool Washer | Spool Washer |
10BXK - Spool Washer - Shimano
2,50 €
|
| 3600 | 103L4 Screw | Screw | — |
| 3747 | 10LSQ Slider Retainer Screw | Slider Retainer Screw | — |
| 4798 | 103C6 Screw | Screw | — |
| 5850 | 10G75 Baitrunner Pawl Spring | Baitrunner Pawl Spring | — |
| 5866 | 109H9 Push Nut | Push Nut | — |
| 5880 | 10MT3 Screw | Screw | — |
| 6597 | 10M2R Screw | Screw | — |
| 6685 | 10PK6 Washer | Washer | — |
| 7419 | 10LLG Screw | Screw | — |
| 7469 | 10PMJ Screw | Screw | — |
| 7927 | 10HWZ Washer | Washer | — |
| 8759 | 106UX Click Pin | Click Pin | — |
| 8776 | 104KM Oil Cap | Oil Cap | — |
| 8916 | 10CH0 Click Spring | Click Spring | — |
| 9087 | 10KFE Line Roller Spacer | Line Roller Spacer | — |
| 9872 | 10PRU Screw | Screw | — |
| 10184 | 10PFH Line Roller Bushing | Line Roller Bushing | — |
| 10318 | 10KZY Line Roller Support | Line Roller Support | — |
| 10348 | 10JX9 Click Spring | Click Spring | — |
| 10367 | 104YE Anti-Reverse Cam | Anti-Reverse Cam | — |
| 10391 | 106XW Bail Trip Cover | Bail Trip Cover | — |
| 10404 | 103N2 Screw | Screw | — |
| 10417 | 10PEL Drag Click | Drag Click | — |
| 10752 | 10TYE Bail Spring Guide A Support | Bail Spring Guide A Support | — |
| 10753 | 10FVD Bail Spring | Bail Spring | — |
| 10756 | 10HEB Bail Spring Seat | Bail Spring Seat | — |
| 11080 | 10DCN Anti-Reverse Cam Spring | Anti-Reverse Cam Spring | — |
| 11146 | 10JDB Washer | Washer | — |
| 13010 | 10D7L Friction Ring | Friction Ring | — |
| 13241 | 104JD Ball Bearing | Ball Bearing |
R18
dès 10,99 €
|
| 13374 | 104Q5 Ball Bearing | Ball Bearing |
R12
dès 13,29 €
|
| 13523 | 10MS6 Drag Knob | Drag Knob | — |
| 13524 | 10PEG Drag Washer | Drag Washer | — |
| 13525 | 10ENX Spool USA Baitrunner 4000 D | Spool USA Baitrunner 4000 D | — |
| 13526 | 10PXK Main Shaft | Main Shaft | — |
| 13527 | 106G9 Counter Weight | Counter Weight | — |
| 13528 | 10P79 Rotor | Rotor | — |
| 13529 | 10KUN Line Roller | Line Roller | — |
| 13530 | 10CZD Line Roller Collar | Line Roller Collar | — |
| 13531 | 10FB4 Bail Trip Lever | Bail Trip Lever | — |
| 13532 | 10JEY Bail Arm | Bail Arm | — |
| 13533 | 10CUJ Bail Spring Cover | Bail Spring Cover | — |
| 13534 | 107WP Bail Hold Support Guard | Bail Hold Support Guard | — |
| 13535 | 107M7 Bail Assembly | Bail Assembly | — |
| 13536 | 10M3U Pinion Gear | Pinion Gear | — |
| 13537 | 10D90 Bail Trip Strike | Bail Trip Strike | — |
| 13538 | 10LR6 Anti-Reverse Lever | Anti-Reverse Lever | — |
| 13539 | 104K8 Drive Gear | Drive Gear | — |
| 13540 | 106S4 Baitrunner Click | Baitrunner Click | — |
| 13541 | 102Q8 Side Cover | Side Cover | — |
| 13542 | 105FC Handle Assembly | Handle Assembly | — |
| 13543 | 10G91 Baitrunner Lever Arm L | Baitrunner Lever Arm L | — |
| 13544 | 106N9 Baitrunner Lever Bridge | Baitrunner Lever Bridge | — |
| 13545 | 10JZR Oscillating Slider Retainer | Oscillating Slider Retainer | — |
| 13546 | 104WN Oscillating Slider | Oscillating Slider | — |
| 13547 | 10PGP Oscillating Gear | Oscillating Gear | — |
| 13548 | 10JVS Oscillating Ratchet Spring | Oscillating Ratchet Spring | — |
| 13549 | 10JVR Oscillating Gear Ratchet | Oscillating Gear Ratchet | — |
| 13550 | 106MV Clutch Arm | Clutch Arm | — |
| 13551 | 10GMW Clutch Cam Spring | Clutch Cam Spring | — |
| 13552 | 10N1U Clutch Spring | Clutch Spring | — |
| 13553 | 10LYS Clutch Cam | Clutch Cam | — |
| 13554 | 106WL Spacer | Spacer | — |
| 13555 | 10P0P Baitrunner Ratchet | Baitrunner Ratchet | — |
| 13556 | 106S2 Dial Retainer | Dial Retainer | — |
| 13557 | 1050W Dial Retainer B | Dial Retainer B | — |
| 13558 | 10N0U Baitrunner Pawl | Baitrunner Pawl | — |
| 13559 | 106RX Dial Click | Dial Click | — |
| 13560 | 10JVT Dial Click Holder | Dial Click Holder | — |
| 13562 | 10NCV Baitrunner Lever Arm R | Baitrunner Lever Arm R | — |
| 13563 | 10GVU Screw | Screw | — |
| 13564 | 10MYR Free Spool Tension Shaft | Free Spool Tension Shaft | — |
| 13565 | 10P2F Washer | Washer | — |
| 13566 | 10LMF Click Gear | Click Gear | — |
| 13567 | 107CS Washer | Washer | — |
| 13568 | 106RT Free Spool Tension Spring | Free Spool Tension Spring | — |
| 13569 | 106RP Screw | Screw | — |
| 13571 | 10LYD Baitrunner Tension Dial | Baitrunner Tension Dial | — |
| 13620 | 10L6D Screw | Screw | — |
| 13706 | 1074X Washer | Washer | — |
| 14489 | 10BQG Screw | Screw | — |
| 15608 | 10FUE Body | Body | — |
| 16395 | 10QP1 Roller Clutch Assembly | Roller Clutch Assembly | — |
| 17398 | 105LU Bail Spring Guide A | Bail Spring Guide A | — |
| 18544 | 10N27 Washer | Washer | — |
