| N° Schéma | Référence / Pièce | Action |
|---|---|---|
| 14 |
R01
|
|
| 26 |
R01
|
|
| 39 |
R04
|
|
| 95 |
R04
|
|
| 70 |
R05
|
|
| 77 |
R05
|
|
| 204 |
R05
|
|
| 82 |
R06
|
| Numéro Schéma | Numéro de la pièce | Description | Option |
|---|---|---|---|
| 68 | 63205901 | Warm Shaft Titnor |
E-Ring 2,5mm
|
| 14 | 6G511506 | RS Ball Bearing |
R01
|
| 26 | 6G511506 | Spool ball bearing |
R01
|
| 39 | 6G431008 | Clutch cam ball bearing |
R04
|
| 95 | 6G431008 | Handle Ball Bearing |
R04
|
| 70 | 6G720001 | Worm Shaft Collar |
R05
|
| 77 | 6G720001 | Worm Shaft Collar |
R05
|
| 204 | 6G469009 | Handle knob ball bearing |
R05
|
| 82 | 6G538007 | Gear - shaft ball bearing |
R06
|
